3 pcs Non retention Sanitary Ball Valve disasembly full port , SS316L , 2 INCH

Nazwa marki:	DONJOY
Numer modelu:	NO.VZB40
MOQ:	Negotiation
Szczegóły opakowania:	carton box
Warunki płatności:	T/T, LC, Credit Card

Szczegółowe informacje

Opis produktu

Szczegółowe informacje

Place of Origin:

CHINA

Orzecznictwo:

CE,3A,FDA

Product Name:

Ball Valve

Size Of Panel:

DN25-DN100

Operation:

Pneumatic, Control Head,Manual

Media:

304/316L

Connection:

Welded, Clamped, Thread, Flange

Pressure:

1000WG

Podkreślić:

electric ball valve

stainless steel ball valve

Opis produktu

3-pcs Non-retention ball valve disasembly full port ball valve,SS316L,2 INCH

Description:

Operation of the ball Valve

1. Pneumatic three-piece mon-retention ball valve

2. Pneumatic three-piece mon-retention ball valve with positioner

3. Pneumatic three-piece mon-retention ball valve with C-TOP

4. Pneumatic three-piece mon-retention ball valve With Mini C-TOP

5. Pneumatic three-piece mon-retention ball valve With Electric actuator

6. Aluminum acuator with positioner

Specification

Product Name:	3-pcs Non-retention ball valve disasembly full port ball valve,SS316L,2 INCH
Valve Body Material:	SS304 or SS316L
Seal Material:	PTFE
Max. Working Pressure:	10Bar
Max. Working Temperature:	150 degree C
Availably size:	DN25-DN100 or 1" - 4"
Availably connection:	Weld,Clamp,Thread, Flange
Availably standard:	DIN,SMS,3A
Ball Type:	Directly
Operated:	Manual,Pneumatic,Electric,control Head
Certificate:	FDA,CE,3A,ISO

Applications:

The ball valve according to 3A and ASME BPE standard design, mainly used in pharmaceutical, food and beverage, wine, chemical and other industires

Technical Feature

All-inclusive tee design, no stranded high clean, meet the requirement of CIP and SIP sterilization and cleaning,and heat resistance of 180degree, the highest pressure 30Bar,automatic compensating sealing design, the advantages of samll torque, long service life

PACKAGING DETAIL: PLASTIC FIRST, THEN CARTON, LAST IN POLYWOOD

DELIVERY DETAIL:DEPEND ON THE REQUEST OF CUSTOMERS' ORDER SCALE.

PAYMENT DETAILS: AYMENT BY L/C OR T/T,WEESTERN UNION..

3 pcs Non retention Sanitary Ball Valve disasembly full port , SS316L , 2 INCH 0

If you still have any problems,Please do not hesitate to contact us.
